Dongshong 400 Cordless Hydraulic Cable Crimper - DCYH400 (TYPE EM)

The Dongshong DCVC800 Cordless Vacuum Cleaner (20V) merges power with intelligence, featuring 16 kPa suction and an advanced HEPA filtration system. Engineered for wet and dry applications, it offers an 8L dust capacity and 3L liquid capacity, alongside dual-speed modes and an automatic protection system. Lightweight and equipped with a shoulder strap, it ensures maximum mobility.

1. Technical Specifications

• Battery: 20V (Max) / 4.0 Ah (Includes two batteries).
• Maximum Power: 400W.
• Max Crimping Force: 120 kN (Approx. 12 Tons).
• Operating Stroke: 42 mm.
• Crimping Range: Copper up to 400 mm², Aluminum up to 300 mm².
• Crimping Cycle: 5 to 15 seconds (depending on cable size).
• Oil Capacity: Approx. 160 ml.
• Recommended Hydraulic Oil: Shell Tellus H2V HV15.
• Operating Temperature: -10°C to 40°C.
• Net Weight: 6.7 kg to 7.3 kg.

2. Key Features

1. High Hydraulic Power: Equipped with a 12-ton hydraulic pump to ensure professional, secure crimping.
2. Rotatable Head: The working head rotates 350 degrees for easy operation in tight spaces and difficult angles.
3. Auto-Retraction Function: Automatically retracts the die after the crimping process is complete to save time and increase efficiency.
4. Manual Reset: Features a manual reset button for safety in case of emergencies or malfunctions during operation.
5. OLED Display: Digital screen clearly displays operating status, battery levels, and alerts.

3. Accessories and Packaging

The device is supplied in a durable plastic carrying case and includes:

• Sealing ring sets for the cylinder and safety valve.
• Carrying straps for ease of transport.
• Crimping Dies (13 pieces): Sizes 10, 16, 25, 35, 50, 70, 95, 120, 150, 185, 240, 300, and 400 mm².

4. Operating Instructions (Summary)

1. Preparation: Select and install the correct crimping die for the specific cable size.
2. Positioning: Place the cable and connector between the jaws (dies).
3. Operation: Press the start button; the motor drives the hydraulic pump to compress the fitting.
4. Monitoring: Track the process via the OLED screen. Once the required pressure is reached, the device will auto-retract.
5. Completion: Remove the cable after the jaws have retracted. Use the manual reset if an emergency stop is required.

5. Warranty

Includes a one-year maintenance warranty.
